What is Motion Planning?

Motion planning asks a deceptively simple question: given a robot, a world, a place the robot is, and a place we want it to be, what should the robot do? The remainder of this book is a sixteen-chapter answer. Before any algorithm appears, this opening chapter nails down the vocabulary, the problem statement, and the map of the field, so that every later chapter can refer back to a shared foundation.

1. Five things that might be called “a plan”

When roboticists say “plan” they mean one of at least five different mathematical objects. Confusing them is the single most common source of early-student bewilderment, so we disambiguate first.

Let $q \in \mathcal{C}$ denote a configuration — a point in the robot’s configuration space $\mathcal{C}$, the set of all possible poses the robot can take. Let $x \in \mathcal{X}$ denote a state — a point in the state space $\mathcal{X}$, which augments the configuration with its time derivatives (velocities) when dynamics matter. Let $u \in \mathcal{U}$ denote a control input — a point in the control space $\mathcal{U}$, the set of commands the robot’s actuators can accept. Let $o \in \mathcal{O}$ denote an observation — a point in the observation space $\mathcal{O}$, the sensor reading the robot sees instead of the true state when perception is incomplete.

The objects form a rough hierarchy of commitment. A path commits to geometry but not timing, so it can be re-parameterised later to respect velocity limits. A trajectory commits to timing. A policy refuses to commit to anything until it sees the current state — it is the most robust to disturbances but also the most expensive to compute, because it must be defined everywhere. A controller is the online machinery that actually closes the loop between a reference (path or trajectory) and the hardware, and is rarely computed by a planner; it is designed once for a robot and reused across many plans.

Example. Consider a Franka Panda arm asked to pick up a mug.

• A path planner (such as an RRT or a PRM) returns a sequence of joint configurations.
• A trajectory optimiser (such as CHOMP or TrajOpt, developed in trajectory optimisation) returns the same geometry with a time parameterisation that respects torque limits.
• A low-level controller (typically a joint-space PD or inverse-dynamics controller, 1 kHz) tracks that trajectory on the real hardware.
• A policy (a learned diffusion policy, say — see the chapter on neural motion planning) could replace all three by mapping directly from camera images to joint torques.
• A task planner (a PDDL solver or an LLM) decides, at a higher level still, that picking the mug comes before placing it; this is the subject of task and motion planning.

Each box in this stack has its own literature, its own failure modes, and its own home in this book.

2. The canonical planning query

Almost every planner in this book solves some version of the following problem.

The 5-tuple $(\mathcal{C}_{\text{free}}, q_s, \mathcal{G}, J, \text{constraints})$ is the contract a motion planner signs. Variants abound:

• If the goal is a region, we have a goal set problem; if a single point, a point-to-point problem.
• If only feasibility is needed, $J$ is irrelevant and we ask for any $\tau \in \mathcal{C}_{\text{free}}$.
• If the environment is uncertain, $\mathcal{C}_{\text{free}}$ is itself a random set and the problem becomes planning under uncertainty.
• If the robot has dynamics, the decision variable is really a control trajectory $u(t)$, and we are in kinodynamic planning.
• If there are multiple robots, $\tau$ is joint and $\mathcal{C}_{\text{free}}$ must forbid robot–robot collision — see multi-robot motion planning.
• If the goal is symbolic (“the mug is on the shelf”), we are in the territory of task and motion planning.

A large part of this book is spent relaxing or strengthening components of this tuple and watching the algorithm change in response.

3. Four properties a planner can have

Every planner in the next fifteen chapters can be classified by which subset of four properties it delivers. No planner delivers all four; knowing which two or three a method provides is how you pick the right tool.

3.1 Completeness

A planner is complete if it returns a solution whenever one exists, and reports failure otherwise in finite time. This is the strong form — rare in practice.

A planner is resolution complete if it is complete up to a discretisation: it finds a solution whenever one exists at a given resolution, and refining the resolution eventually finds any solution with positive clearance. Grid-based A* is resolution complete.

A planner is probabilistically complete if, given more and more random samples, the probability of returning a solution (when one exists) approaches 1. RRT and PRM are probabilistically complete.

3.2 Optimality

A planner is optimal if it returns a minimum-cost solution. Dijkstra on a finite graph is exactly optimal. A planner is asymptotically optimal if the cost of its returned solution converges to the optimum as the computational budget grows; RRT*, PRM*, and BIT* (developed in optimal sampling-based planning) are asymptotically optimal. Anytime planners additionally return the best-so-far solution at any interruption point.

3.3 Real-time guarantees

Some planners can be stopped at any time and will return a valid (if suboptimal) plan; others must run to completion. Anytime algorithms give the former. Reactive controllers such as artificial potential fields and the dynamic window approach — covered in reactive and local planning — give extreme real-time behaviour at the cost of global reasoning.

3.4 Robustness

Does the plan still work if the model was slightly wrong? If the robot state is noisy? Classical planners produce plans that are valid in expectation of a nominal model; robust planners account explicitly for bounded uncertainty; stochastic planners optimise expected cost under a distribution. Planning under uncertainty explores this axis in depth.

Here is a small cheat-sheet, which the remainder of the book will gradually populate. The method names are unlinked in the table to keep it readable; each is introduced and linked in its home chapter.

The table deliberately contains red ink. A real robot stack blends several rows.

4. Three algorithmic families (plus one)

Almost every planner ever written lives in one of these boxes:

Search-based planning. Build an explicit or implicit graph over discrete states; run a shortest-path algorithm — A*, Dijkstra, D*, ARA*, all developed in discrete planning. The classical “discrete” approach. Works when the graph is small enough to enumerate or when good heuristics prune the search.

Sampling-based planning. Sample configurations from $\mathcal{C}$, connect them with a local planner, and build an increasingly rich graph (PRM) or tree (RRT), with asymptotically-optimal variants (FMT*, BIT*) covered in optimal sampling-based planning. Works in high dimensions where a full grid is intractable.

Optimisation-based planning. Parameterise a trajectory as a decision variable in a nonlinear programme; minimise a smoothness + collision objective. Methods such as CHOMP, STOMP, TrajOpt, and GCS are developed in trajectory optimisation. Gives smooth, locally optimal paths, but depends heavily on initialisation.

Reactive and local planning sits slightly outside this taxonomy. Artificial potential fields, the dynamic window approach, and velocity obstacles — covered in reactive and local planning — do not plan in the global sense; they react to a local cost landscape. They are essential as the fast inner loop of hybrid systems but cannot solve hard connectivity problems on their own.

A practical modern system typically uses at least two families together: a global sampling-based or search-based planner for topology, a local optimiser for smoothness, and a reactive controller for execution under disturbances. The chapter on software, benchmarks, and reproducibility surveys how OMPL, MoveIt, and Drake arrange these layers in practice.

5. A brief tour of what is not in this book

To keep the scope finite, the book deliberately omits several adjacent topics:

• Perception and SLAM. We assume the environment model is given. In practice it comes from simultaneous localisation and mapping, object detection, and scene understanding — all fields of their own.
• Low-level control. We assume that once a trajectory is produced, a controller (PID, computed-torque, impedance) can follow it. Control theory is its own subject.
• Full stochastic optimal control. Planning under uncertainty touches model predictive control and belief-space planning but does not cover the LQG, H-infinity, or sum-of-squares machinery in depth.
• Classical AI planning (PDDL, STRIPS). The chapter on task and motion planning uses symbolic task planning as a black box; it does not teach STRIPS from scratch.
• Legged locomotion and bipedal walking. These use motion planning heavily but are typically taught as a specialised course; the hybrid-dynamics issues there deserve their own treatment.

For each of these, pointers to the right external resource are given in the references.

6. The hardness of motion planning

It would be dishonest to finish this chapter without admitting that the general problem is hard.

PSPACE-hard means that, unless $\text{P} = \text{PSPACE}$, no polynomial-time algorithm exists. The practical consequence is:

The intellectual arc of the next fifteen chapters is precisely the engineering compromise this theorem forces: we trade exactness for scalability, and try to recover as many guarantees as we can along the way.

7. Notation

The following symbols are used consistently throughout the book. Later chapters introduce additional notation as needed.

8. Worked example: a Roomba, a warehouse robot, and a surgical needle

To cement the 5-tuple and the family taxonomy, we identify them explicitly for three canonical robots.

8.1 Roomba (autonomous vacuum)

• $\mathcal{C}$: $SE(2)$ (planar rigid body, 3 DoF).
• $\mathcal{C}_{\text{free}}$: a 2D occupancy map built online from bumper and IR sensors.
• $q_s$: current pose.
• $\mathcal{G}$: “cover the entire free space” — a coverage query, not a point-to-point query.
• $J$: time, or battery energy.
• Constraints: nonholonomic (cannot slide sideways); bounded linear and angular velocities.
• Family: mostly reactive local planning plus a high-level grid-based coverage planner (developed in reactive and local planning and discrete planning). Real-time is non-negotiable; robustness to mis-localisation matters more than optimality.

8.2 Warehouse fleet (100 robots moving pallets)

• $\mathcal{C}$: a discrete graph (aisle grid), one copy per robot — joint configuration lives in the product graph.
• $\mathcal{C}_{\text{free}}$: joint-graph positions where no two robots collide.
• $q_s$: current locations of all robots.
• $\mathcal{G}$: assignments of each robot to a goal cell.
• $J$: sum-of-costs or makespan.
• Family: multi-agent pathfinding, specifically Conflict-Based Search variants. Optimality does matter because a 5 % improvement translates to seven-digit operating savings.

8.3 Steerable needle for prostate brachytherapy

• $\mathcal{C}$: $SE(3)$ of the needle tip, but with nonholonomic constraints from the bevel tip’s constant curvature.
• $\mathcal{C}_{\text{free}}$: the patient anatomy minus critical structures (urethra, rectum).
• $q_s$: insertion point on the skin.
• $\mathcal{G}$: the tumour region (a set, not a point).
• $J$: dose delivered to tumour minus dose to healthy tissue.
• Constraints: the needle can only curve in one direction without rotation; tissue deformation under insertion forces.
• Family: kinodynamic sampling-based planning, often with a learned tissue model and belief-space corrections.

Each example is revisited at least once in later chapters; together they span the three hardest dimensions of the field — high DoF, many agents, and uncertainty.
